Manufacturer: CISCO

Cisco Catalyst C1000-24T-4X-L network switch Managed L2 Gigabit Ethernet (10/100/1000) Grey

€2130.68 incl tax

SKU: ST04587852

Manufacturer part number: C1000-24T-4X-L

Manufacturer Homepage

Warranty: 24 months

Stock *

	Stock	Delivery	Quantity	Price
	PL	8 - 15 days	1	€2130.68 incl tax

Qty:

Specifications

Products specifications

1
Details 2
Details 3

RJ-45 port	24
Properties	RJ-45
Properties	USB

Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Y
Web-based management	Y
Traffic classification	Y
ARP inspection	Y
Configuring Location Settings (CLI)	Y
MIB support	Y
Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Installed SFP+ modules quantity	4
Console port	RJ-45/Mini-USB
USB 2.0 ports quantity	1
Networking standards	IEEE 802.1AX,IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3ad,IEEE 802.3ae,IEEE 802.3af,IEEE 802.3ah,IEEE 802.3at,IEEE 802.3az,IEEE 802.3u
10G support	Y
Full duplex	Y
Link aggregation	Y
Broadcast storm control	Y
Auto MDI/MDI-X	Y
Spanning tree protocol	Y
Ethernet LAN data rates	100,1000,10000 Mbit/s
VLAN support	Y
Number of VLANs	4094
MAC address table	16000 entries
Switching capacity	128 Gbit/s
Forwarding rate	41.67 Mpps
Static route	Y
Number of static routes	16
Jumbo frames support	Y
Jumbo frames	10240
DHCP features	DHCP snooping
Access Control List (ACL)	Y
IGMP snooping	Y
IGMP entries	1024
SSH/SSL support	Y
Loop protection	Y
BPDU filtering/protection	Y
Authentication	Web-based authentication
Authentication type	RADIUS
Multicast support	Y
IPv4 multicast entries	1024
IPv6 multicast entries	1024
Product colour	Grey
LED indicators	Y
Certification	UL 60950-1 Second Edition, CAN/CSA-C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, AS/NZS 60950-1 47CFR Part 15 (CFR 47) Class A, AS/NZS CISPR22 Class A, CISPR22 Class A, EN55022 Class A, ICES003 Class A, VCCI Class A, EN61000-3-2, EN61000-3-3, KN22 Class A, CNS13438 Class A EN55024 (including EN 61000-4-5), CISPR24, EN300386, KN24 Reduction of Hazardous Substances (RoHS) including Directive 2011/65/EU Common Language Equipment Identifier (CLEI) code
Built-in processor	Y
Processor model	ARM7
Processor frequency	800 MHz
Memory type	DRAM
Internal memory	512 MB
Flash memory	256 MB
Mean time between failures (MTBF)	2026793 h
AC input voltage	110 - 220 V
AC input frequency	50/60 Hz
Power over Ethernet (PoE)	N
Operating temperature (T-T)	-5 - 50 °C
Storage temperature (T-T)	-25 - 70 °C
Operating relative humidity (H-H)	5 - 90%
Storage relative humidity (H-H)	5 - 95%
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4500 m
Width	444.5 mm
Depth	240 mm
Height	44 mm
Weight	2.78 kg
Description
Description	Cisco Catalyst C1000-24T-4X-L. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24, Installed SFP+ modules quantity: 4, USB 2.0 ports quantity: 1, Console port: RJ-45/Mini-USB. Full duplex. MAC address table: 16000 entries, Switching capacity: 128 Gbit/s. Networking standards: IEEE 802.1AX,IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE...

Description	CISCO Catalyst 1000 24-Port Gigabit data
VatType	VAT
Weight	4.310000000
Height	165.000000000
Width	350.000000000
Length	560.000000000
Description
Description	CISCO Catalyst 1000 24-Port Gigabit data-only 4 x 10G SFP+ Uplinks LAN Base

Products specifications

1
Details 2
Details 3

RJ-45 port	24
Properties	RJ-45
Properties	USB

Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Y
Web-based management	Y
Traffic classification	Y
ARP inspection	Y
Configuring Location Settings (CLI)	Y
MIB support	Y
Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Installed SFP+ modules quantity	4
Console port	RJ-45/Mini-USB
USB 2.0 ports quantity	1
Networking standards	IEEE 802.1AX,IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3ad,IEEE 802.3ae,IEEE 802.3af,IEEE 802.3ah,IEEE 802.3at,IEEE 802.3az,IEEE 802.3u
10G support	Y
Full duplex	Y
Link aggregation	Y
Broadcast storm control	Y
Auto MDI/MDI-X	Y
Spanning tree protocol	Y
Ethernet LAN data rates	100,1000,10000 Mbit/s
VLAN support	Y
Number of VLANs	4094
MAC address table	16000 entries
Switching capacity	128 Gbit/s
Forwarding rate	41.67 Mpps
Static route	Y
Number of static routes	16
Jumbo frames support	Y
Jumbo frames	10240
DHCP features	DHCP snooping
Access Control List (ACL)	Y
IGMP snooping	Y
IGMP entries	1024
SSH/SSL support	Y
Loop protection	Y
BPDU filtering/protection	Y
Authentication	Web-based authentication
Authentication type	RADIUS
Multicast support	Y
IPv4 multicast entries	1024
IPv6 multicast entries	1024
Product colour	Grey
LED indicators	Y
Certification	UL 60950-1 Second Edition, CAN/CSA-C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, AS/NZS 60950-1 47CFR Part 15 (CFR 47) Class A, AS/NZS CISPR22 Class A, CISPR22 Class A, EN55022 Class A, ICES003 Class A, VCCI Class A, EN61000-3-2, EN61000-3-3, KN22 Class A, CNS13438 Class A EN55024 (including EN 61000-4-5), CISPR24, EN300386, KN24 Reduction of Hazardous Substances (RoHS) including Directive 2011/65/EU Common Language Equipment Identifier (CLEI) code
Built-in processor	Y
Processor model	ARM7
Processor frequency	800 MHz
Memory type	DRAM
Internal memory	512 MB
Flash memory	256 MB
Mean time between failures (MTBF)	2026793 h
AC input voltage	110 - 220 V
AC input frequency	50/60 Hz
Power over Ethernet (PoE)	N
Operating temperature (T-T)	-5 - 50 °C
Storage temperature (T-T)	-25 - 70 °C
Operating relative humidity (H-H)	5 - 90%
Storage relative humidity (H-H)	5 - 95%
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4500 m
Width	444.5 mm
Depth	240 mm
Height	44 mm
Weight	2.78 kg
Description
Description	Cisco Catalyst C1000-24T-4X-L. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24, Installed SFP+ modules quantity: 4, USB 2.0 ports quantity: 1, Console port: RJ-45/Mini-USB. Full duplex. MAC address table: 16000 entries, Switching capacity: 128 Gbit/s. Networking standards: IEEE 802.1AX,IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE...

Description	CISCO Catalyst 1000 24-Port Gigabit data
VatType	VAT
Weight	4.310000000
Height	165.000000000
Width	350.000000000
Length	560.000000000
Description
Description	CISCO Catalyst 1000 24-Port Gigabit data-only 4 x 10G SFP+ Uplinks LAN Base
