    • Level One LevelOne POW-2442 barošanas avotu vienība 120 W Zils, Sudrabs
    Manufacturer: LEVELONE

    Level One LevelOne POW-2442 barošanas avotu vienība 120 W Zils, Sudrabs


    €84.31 incl tax

    SKU: ST08144930
    Manufacturer part number: POW-2442
    Manufacturer Homepage
    Warranty: 12 months
    *
    Stock Delivery Quantity Price
    LV
    PL

    Products specifications
    weight530 g
    height125.2 mm
    width40 mm
    depth113.5 mm
    country of originChina
    product colourBlue, Silver
    mean time between failures (mtbf)2636800 h
    operating temperature (t-t)-20 - 70 °C
    operating relative humidity (h-h)0 - 90%
    package width60 mm
    package depth140 mm
    package height143 mm
    package weight700 g
    harmonized system (hs) code8504403090
    package typeBox
    ac input voltage90 -264 V
    ac input frequency47 - 63 Hz
    input current2.25 A
    master (outer) case gross weight14 kg
    master (outer) cases per pallet20 pc(s)
    master (outer) case width310 mm
    master (outer) case length310 mm
    master (outer) case height305 mm
    maximum current5 A
    safetyEN 55032 (CISPR32) Class A EN 61000-3-2,-3,EACTPTC020,CNS13438 Class A EN 61000-4-2,3,4,5,6,8,11 EN 61204-3 EN 55035 EN 61000-6-2 (EN 50082-2) MTBF:2636.8K hrs min. Telcordia SR-332 (Bellcore)
    number of fans0 fan(s)
    power protection featuresOverload, Over voltage, Short circuit
    total power120 W
    output voltage note24V
    hold time16 ms
    voltage tolerance1%
    Description
    LevelOne POW-2442. Kopējā jauda: 120 W, Maiņstrāvas ievades spriegums: 90 -264 V, Maiņstrāvas ievades frekvence: 47 - 63 Hz. Vidējais laiks starp kļūmēm (MTBF): 2636800 h. Produkta krāsa: Zils, Sudrabs. Drošība: EN 55032 (CISPR32) Class A EN 61000-3-2,-3,EACTPTC020,CNS13438 Class A EN 61000-4-2,3,4,5,6,8,11.... Platums: 40 mm, Dziļums: 113,5 mm, Augstums: 125,2 mm

    Products specifications
    weight530 g
    height125.2 mm
    width40 mm
    depth113.5 mm
    country of originChina
    product colourBlue, Silver
    mean time between failures (mtbf)2636800 h
    operating temperature (t-t)-20 - 70 °C
    operating relative humidity (h-h)0 - 90%
    package width60 mm
    package depth140 mm
    package height143 mm
    package weight700 g
    harmonized system (hs) code8504403090
    package typeBox
    ac input voltage90 -264 V
    ac input frequency47 - 63 Hz
    input current2.25 A
    master (outer) case gross weight14 kg
    master (outer) cases per pallet20 pc(s)
    master (outer) case width310 mm
    master (outer) case length310 mm
    master (outer) case height305 mm
    maximum current5 A
    safetyEN 55032 (CISPR32) Class A EN 61000-3-2,-3,EACTPTC020,CNS13438 Class A EN 61000-4-2,3,4,5,6,8,11 EN 61204-3 EN 55035 EN 61000-6-2 (EN 50082-2) MTBF:2636.8K hrs min. Telcordia SR-332 (Bellcore)
    number of fans0 fan(s)
    power protection featuresOverload, Over voltage, Short circuit
    total power120 W
    output voltage note24V
    hold time16 ms
    voltage tolerance1%
    Description
    LevelOne POW-2442. Kopējā jauda: 120 W, Maiņstrāvas ievades spriegums: 90 -264 V, Maiņstrāvas ievades frekvence: 47 - 63 Hz. Vidējais laiks starp kļūmēm (MTBF): 2636800 h. Produkta krāsa: Zils, Sudrabs. Drošība: EN 55032 (CISPR32) Class A EN 61000-3-2,-3,EACTPTC020,CNS13438 Class A EN 61000-4-2,3,4,5,6,8,11.... Platums: 40 mm, Dziļums: 113,5 mm, Augstums: 125,2 mm
