    • Level One LevelOne POW-4822 barošanas avotu vienība 75 W Zils, Sudrabs
    Manufacturer: LEVELONE

    Level One LevelOne POW-4822 barošanas avotu vienība 75 W Zils, Sudrabs


    €82.75 incl tax

    SKU: ST08074911
    Manufacturer part number: POW-4822
    Manufacturer Homepage
    Warranty: 12 months
    *
    Stock Delivery Quantity Price
    LV
    PL

    Products specifications
    weight430 g
    height125.2 mm
    width32 mm
    depth102 mm
    peak power76.8 W
    country of originChina
    product colourBlue, Silver
    mean time between failures (mtbf)486200 h
    operating temperature (t-t)-20 - 70 °C
    operating relative humidity (h-h)0 - 90%
    package width53 mm
    package depth132 mm
    package height147 mm
    package weight500 g
    harmonized system (hs) code8504403090
    package typeBox
    ac input voltage90 -264 V
    ac input frequency47 - 63 Hz
    input current1.45 A
    master (outer) case gross weight16.8 kg
    master (outer) cases per pallet20 pc(s)
    master (outer) case width282 mm
    master (outer) case length313 mm
    master (outer) case height393 mm
    safetyEN 55032 (CISPR32) Class A EN 61000-3-2,-3,EACTPTC020,CNS13438 Class A EN 61000-4-2,3,4,5,6,8,11 EN 61204-3 EN 55035 EN 61000-6-2 (EN 50082-2)
    power protection featuresOverload, Over voltage, Short circuit
    total power75 W
    output voltage note48V
    hold time16 ms
    voltage tolerance1%
    Description
    LevelOne POW-4822. Kopējā jauda: 75 W, Maiņstrāvas ievades spriegums: 90 -264 V, Augstākā jauda: 76,8 W. Vidējais laiks starp kļūmēm (MTBF): 486200 h. Produkta krāsa: Zils, Sudrabs. Drošība: EN 55032 (CISPR32) Class A EN 61000-3-2,-3,EACTPTC020,CNS13438 Class A EN 61000-4-2,3,4,5,6,8,11.... Platums: 32 mm, Dziļums: 102 mm, Augstums: 125,2 mm

    Products specifications
    weight430 g
    height125.2 mm
    width32 mm
    depth102 mm
    peak power76.8 W
    country of originChina
    product colourBlue, Silver
    mean time between failures (mtbf)486200 h
    operating temperature (t-t)-20 - 70 °C
    operating relative humidity (h-h)0 - 90%
    package width53 mm
    package depth132 mm
    package height147 mm
    package weight500 g
    harmonized system (hs) code8504403090
    package typeBox
    ac input voltage90 -264 V
    ac input frequency47 - 63 Hz
    input current1.45 A
    master (outer) case gross weight16.8 kg
    master (outer) cases per pallet20 pc(s)
    master (outer) case width282 mm
    master (outer) case length313 mm
    master (outer) case height393 mm
    safetyEN 55032 (CISPR32) Class A EN 61000-3-2,-3,EACTPTC020,CNS13438 Class A EN 61000-4-2,3,4,5,6,8,11 EN 61204-3 EN 55035 EN 61000-6-2 (EN 50082-2)
    power protection featuresOverload, Over voltage, Short circuit
    total power75 W
    output voltage note48V
    hold time16 ms
    voltage tolerance1%
    Description
    LevelOne POW-4822. Kopējā jauda: 75 W, Maiņstrāvas ievades spriegums: 90 -264 V, Augstākā jauda: 76,8 W. Vidējais laiks starp kļūmēm (MTBF): 486200 h. Produkta krāsa: Zils, Sudrabs. Drošība: EN 55032 (CISPR32) Class A EN 61000-3-2,-3,EACTPTC020,CNS13438 Class A EN 61000-4-2,3,4,5,6,8,11.... Platums: 32 mm, Dziļums: 102 mm, Augstums: 125,2 mm
