    • Level One LevelOne SFP-4330 tīkla raiduztvērēja modulis Optiskā škiedra 1250 Mbit/s
    Manufacturer: LEVELONE

    Level One LevelOne SFP-4330 tīkla raiduztvērēja modulis Optiskā škiedra 1250 Mbit/s


    €46.05 incl tax

    SKU: ST09571163
    Manufacturer part number: SFP-4330
    Manufacturer Homepage
    Warranty: 12 months
    *
    Stock Delivery Quantity Price
    LV

    Products specifications
    weight19 g
    maximum data transfer rate1250 Mbit/s
    height12.4 mm
    width13.7 mm
    depth56.6 mm
    country of originChina
    product colourSilver
    operating temperature (t-t)0 - 70 °C
    storage temperature (t-t)-40 - 85 °C
    operating relative humidity (h-h)0 - 85%
    package width65 mm
    package depth106 mm
    package height20 mm
    package weight39.5 g
    certificationCE
    harmonized system (hs) code85369010
    quantity per pack1 pc(s)
    package typeBox
    compliance certificatesRoHS
    maximum transfer distance20000 m
    fiber cable diameters supported (core/cladding)9/125 µm
    tx power (min)-9 dBmW
    tx power (max)-3 dBmW
    fiber optic connectorLC
    hot-swapYes
    master (outer) case gross weight6.67 kg
    products per pallet35 pc(s)
    master (outer) case width310 mm
    master (outer) case length375 mm
    master (outer) case height268 mm
    products per master (outer) case150 pc(s)
    user guideYes
    pallet gross width120 cm
    pallet gross length80 cm
    power consumption (typical)1 W
    pallet height (air)166.9 cm
    sfp transceiver typeFiber optic
    interface typeSFP
    multi-mode fiber (mmf) supportedNo
    single-mode fiber (smf) supportedYes
    maximum voltage3.47 V
    maximum current0.3 A
    safetyFCC Part 15 Class B EN55022 Class B (CISPR 22B) VCCI Class B
    rx power (min)-25 dBmW
    rx power (max)-2 dBmW
    tx wavelength (max)1310 nm
    rx wavelength (max)1550 nm
    digital diagnostics monitoring (ddm)Yes
    rx sensitivity-25 dB
    Description
    LevelOne SFP-4330. SFP veids raiduztvērēja veids: Optiskā škiedra, Maksimālais datu pārraides ātrums: 1250 Mbit/s, Interfeisa tips: SFP. Produkta krāsa: Sudrabs. Maksimālā jauda: 3,47 V, Maksimālā strāva: 0,3 A, Enerģija patēriņš: 1 W. Atbilstības sertifikāti: RoHS, Drošība: FCC Part 15 Class B EN55022 Class B (CISPR 22B) VCCI Class B, Sertifikācija: CE. Platums: 13,7 mm, Dziļums: 56,6 mm, Augstums: 12,4 mm
