| plug and play | Yes |
| weight | 80 g |
| gross weight | 0.35 |
| height | 20 mm |
| width | 52 mm |
| depth | 60 mm |
| country of origin | CN |
| product colour | Black |
| operating temperature (t-t) | 0 - 50 °C |
| storage temperature (t-t) | -20 - 70 °C |
| operating relative humidity (h-h) | 20 - 80% |
| harmonized system (hs) code | 84719000 |
| ports quantity | 4 |
| housing material | Metal |
| ethernet lan (rj-45) ports | 1 |
| host interface | USB 2.0 |
| hub interfaces | RJ-45, USB 2.0 |
| usb 2.0 ports quantity | 4 |
| cable colour | Black |
| net weight | 0.25 |
| packaging height | 8.50 |
| packaging lenght | 17.90 |
| packaging width | 9.40 |
| warranty | 2 |
| ce doc | https://files.plytix.com/api/v1.1/file/public_files/pim/assets/30/18/3c/62/623c1830be3c59cb8b1e1693/texts/10/6d/11/65/65116d10d866e117e5dab8e4/CE_DoC_DE_42679.pdf |
| ce docs | https://files.plytix.com/api/v1.1/file/public_files/pim/assets/30/18/3c/62/623c1830be3c59cb8b1e1693/texts/10/6d/11/65/65116d10d866e117e5dab8e4/CE_DoC_DE_42679.pdf |
| manuals | https://files.plytix.com/api/v1.1/file/public_files/pim/assets/30/18/3c/62/623c1830be3c59cb8b1e1693/texts/12/ea/70/68/6870ea129b50dd16ecb2785a/LINDY_42679_MAN_0725.pdf,https://files.plytix.com/api/v1.1/file/public_files/pim/assets/30/18/3c/62/623c1830be3c59cb8b1e1693/texts/8a/85/dc/64/64dc858a6dca5c0ee7e15225/LINDY_42679_MAN_0823.pdf,https://files.plytix.com/api/v1.1/file/public_files/pim/assets/30/18/3c/62/623c1830be3c59cb8b1e1693/texts/91/67/97/62/62976791999c8d635dc13d04/Lindy_42679_MAN_0221.pdf |
| Description |
Specifications - USB Standard: USB 2.0
- Supported Bandwidth: 480Mbps
- Maximum Distance: 60m (196.85ft)
- Transmission Medium: Cat.5e/6 or higher network cable
- Chipset: LT-8311
- Special Features: Supports control, bulk, interrupt, synchronous and isochronous data transfer
Connectors - Transmitter Input: USB Type A (Male)
- Transmitter Output: RJ45 (Female)
- Receiver Input: RJ45 (Female)
- Receiver Output: 4 x USB Type A (Female)
- Power: 3.5/1.35mm DC socket
Physical Properties - Dimensions WxDxH: 52x60x23mm (2.05x2.36x0.91in)
- Housing Material: Plastic
- Net Weight: 0.08kg (0.18lb)
- Operating Temperature: -10°C - 60°C (14°F - 140°F)
- Storage Temperature: -20°C - 70°C (-4°F - 158°F)
- Humidity: 0 - 80% RH (non-condensing)
- Power Requirements: 5VDC 4A
- Colour: Black
Miscellaneous - Packaging Type: Carton Box
- Packaging Dimensions: 170x140x70mm (6.69x5.91x2.76in)
- Gross Weight: 0.36kg (0.79lb)
- Warranty (Years): 2
- Product Compliance: CE, FCC, RoHS & REACH
Package Contents - Transmitter unit
- Receiver unit
- Multi-Country Power Supply (EU, UK, US & AUS)
- Lindy Manual
Purchasing Information - No.: 42679
- EAN: 4002888426794
