Ražotājs: INTELLINET

Intellinet 508278 tīkla pārslēgs Vadīts L2+/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Melns

€438,60 ar pvn

Artikuls: ST09558493

Preces kods: 508278

Ražotāja mājaslapa

Garantija: 12 mēneši

Pieejamība *

	Noliktava	Piegāde	Daudzums	Cena
	LV	7 - 12 dienās	1	€438,60 ar pvn

Daudzums:

Specifikācijas

Specifikācija

auto mdi/mdi-x

Yes

power over ethernet (poe)

Yes

international protection (ip) code

IP30

weight

448 g

height

55 mm

width

140 mm

depth

175 mm

full duplex

Yes

auto-negotiation

Yes

switch type

Managed

switch layer

L2+/L3

quality of service (qos) support

Yes

web-based management

Yes

basic switching rj-45 ethernet ports quantity

basic switching rj-45 ethernet ports type

Gigabit Ethernet (10/100/1000)

gigabit ethernet (copper) ports quantity

sfp module slots quantity

networking standards

IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z

10g support

copper ethernet cabling technology

10BASE-T, 100BASE-TX

cable types supported

Cat3, Cat4, Cat5, Cat5e

port mirroring

Yes

flow control support

Yes

link aggregation

Yes

mac address table

8192 entries

switching capacity

20 Gbit/s

store-and-forward

Yes

product colour

Black

led indicators

Activity, Link, Power

power consumption (max)

255 W

total power over ethernet (poe) budget

240 W

operating temperature (t-t)

-40 - 85 °C

storage temperature (t-t)

-40 - 85 °C

operating relative humidity (h-h)

5 - 95%

package width

195 mm

package depth

225 mm

package height

105 mm

package weight

1.6 kg

package type

Box

compliance certificates

Federal Communications Commission (FCC), National Defense Authorization Act (NDAA), UKCA, CE

power source

PoE

housing material

Metal

master (outer) case gross weight

17.2 kg

master (outer) case width

415 mm

master (outer) case length

545 mm

master (outer) case height

243 mm

products per master (outer) case

10 pc(s)

jumbo frames support

Yes

sustainability compliance

Yes

reset button

Yes

jumbo frames

9000

igmp snooping

Yes

surge protection

Yes

power protection features

Over voltage, Overload, Short circuit

spanning tree protocol

Yes

fanless

Yes

dc input voltage

45 - 57 V

mac address auto-learning supported

Yes

mac address auto-aging supported

Yes

vlan support

Yes

broadcast storm control

Yes

rate limiting

Yes

redundant power supply (rps) support

Yes

packet forwarding rate (1 gbps)

1488000 pps

packet forwarding rate (100 mbps)

148800 pps

packet forwarding rate (10 mbps)

14880 pps

fiber ethernet cabling technology

1000BASE-X

virtual lan features

Port-based VLAN, Tagged VLAN

half duplex

Yes

console port

RJ-45

din rail mounting

Yes

power over ethernet (poe) power per port

30 W

auto-sensing

Yes

surge protection voltage

6 kV

Description

Intellinet 508278. Slēdža tips: Vadīts, Slēdža līmenis: L2+/L3. Basic switching RJ-45 Ethernet portu veids: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet portu daudzums: 8, Konsoles pieslēgvieta: RJ-45. Pilns duplekss. Adrešu tabulas izmērs: 8192 ieraksti, Komutācijas ietilpība: 20 Gbit/s. Tīkla standarts: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE.... DC ievades spriegums: 45 - 57 V. Power over Ethernet (PoE)
