| manufacturer | APC |
| product group | USV |
| product type | UPS Line Interactive |
| colour | black |
| weight | 5.7 kg |
| height of packaging (single piece) | 0 mm |
| width of packaging (single piece) | 0 mm |
| depth of packaging (single piece) | 0 mm |
| package weight (single piece) | 7 kg |
| gross weight | 7 |
| current catalog edition | 24.1 |
| scope of delivery | Benutzerhandbuch |
| height | 92 mm |
| width | 160 mm |
| depth | 305 mm |
| operating temperature min. | 0 °C |
| operating temperature max. | 40 °C |
| dimensions (hxwxd) | 92 x 160 x 305 mm |
| cable length | 1.52 m |
| battery capacity | 9 VAh |
| classification (iec 62040-3) | VI-SS-313 |
| ups technology | Line Interactive |
| output (va/w) | 1000 / 600 |
| backup time full/half-load | 3 / 5 min |
| voltage (input) | 230V |
| voltage (output) | 230V |
| frequency | 50/60 Hz +/-1 Hz |
| connector type (output) | 6 Kaltgeräte IEC 320 C13 |
| phase in/output | 230V/230V / 50Hz |
| ambient temperature | 0-40°C |
| output voltage regulation | 10% |
| activity led | LED |
| product colour | Black |
| noise level | 40 dB |
| operating temperature (t-t) | 0 - 40 °C |
| operating relative humidity (h-h) | 0 - 90% |
| package width | 143 mm |
| package depth | 373 mm |
| package height | 237 mm |
| package weight | 6 kg |
| certification | CE |
| harmonized system (hs) code | 85078000 |
| battery type | leakproof |
| compliance certificates | RoHS |
| manual | Yes |
| output voltage | 230 V |
| ac outlets quantity | 1 AC outlet(s) |
| ac outlet types | C13 coupler |
| ups topology | Line-Interactive |
| output power capacity | 1 kVA |
| output power | 600 W |
| waveform | Sine |
| input operation voltage (min) | 170 V |
| input operation voltage (max) | 280 V |
| input frequency | 50/60 Hz |
| output operation voltage (min) | 0 V |
| output operation voltage (max) | 0 V |
| output frequency regulation | 50/60 Hz |
| automatic voltage regulation (avr) | Yes |
| surge energy rating | 156 J |
| surge protection | Yes |
| audible alarm(s) | Yes |
| battery life (max) | 5 year(s) |
| battery recharge time | 8 h |
| audible alarm modes | Low battery alarm, Overload alarm |
| output frequency | 50/60 Hz |
| transfer time (line mode to battery mode) | 6 ms |
| Description |
APC BV1000I. UPS topoloģija: Line-Interactive, Izejas jaudas kapacitāte (VA): 1 kilovoltampērs, Izejas jauda: 600 W. Maiņstrāvas izeju tipi: C13 uzmava, Izeju skaits: 1 Maiņstrāvas izvade (-s). Akumulatora ietilpība: 9 volt-ampērstunda, Akumulatora darbības laiks (maks.): 5 gads(i), Baterijas uzlādes laiks: 8 h. Produkta krāsa: Melns, Kabeļa garums: 1,52 m. Atbilstības sertifikāti: RoHS, Sertifikācija: CE
|
|
