| Features and specifications | | Technology | | | Projection System | 3LCD Technology, RGB liquid crystal shutter | | LCD Panel | 0.62 inch with C2 Fine | | Image | | | Color Light Output | 4,100 Lumen- 2,800 Lumen (economy) In accordance with IDMS15.4 | | White Light Output | 4,100 Lumen - 2,800 Lumen (economy) In accordance with ISO 21118:2020 | | Resolution | 1080p | | High Definition | Full HD | | Aspect Ratio | 16:9 | | Contrast Ratio | Over 2,500,000 : 1 | | Light source | Laser | | Laser Light source | 20,000 hours Durability High, 30,000 hours Durability Eco | | Keystone Correction | Manual vertical: ± 3 °, Manual horizontal ± 3 ° | | Colour Video Processing | 10 Bits | | 2D Vertical Refresh Rate | 192 Hz - 240 Hz | | Colour Reproduction | Upto 1.07 billion colours | | Optical | | | Throw Ratio | 0.25 - 0.35:1 | | Zoom | Digital, Factor: 1 - 1.35 | | Lens | Optical | | Screen Size | 60 inches - 150 inches | | Projection Lens F Number | 1.6 | | Projection Lens Focal Length | 3.7 mm | | Projection Lens Focus | Manual | | Offset | 5 : 1 | | Connectivity | | | Interfaces | USB 2.0-A (2x), RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11a/b/g/n/ac, VGA in (2x), VGA out, HDMI in (3x), Composite in, Miracast, Jack plug out, Jack plug in (3x), USB 2.0 Type B (Service Only), Wi-Fi Direct, Microphone input | | Epson iProjection App | Ad-Hoc / Infrastructure | | Network Protocol | HTTPS, IPv4, IPv6, SNMP, ESC/VP.net, PJLink | | Advanced Features | | | Security | Kensington lock, Control panel lock, Padlock, Security cable hole, Wireless LAN unit lock, Wireless LAN security, Password protection | | Other features | 21:9 aspect ratio support, A/V mute, Arc Correction, Auto Power On, Auto source search, Built-in speaker, CEC compatible, Customizable user logo, Digital zoom, Direct Power on/off, Document Camera Compatible, Edge Blending, Email notification, Home Screen, Horizontal and vertical keystone correction, Image Shift, JPEG Viewer, Long light source life, Network projection, OSD copy function, PC Free, Point correction, Power on button, Quick Corner, Schedule Function, Screen Mirroring, Split-Screen-Function, Ultra-wide display (16:6), Web Control, Web Remote, Wireless LAN capable, iProjection App | | Video Color Modes | Blackboard, Cinema, Dynamic, Presentation, sRGB, DICOM SIM, Multi Projection | | Projector control | via: Crestron Integrated Partner, Crestron RoomView, Extron IP Link, AMX Device Discovery, Control4 Simple Device Discovery Protocol | | General | | | Power consumption | 263 Watt, 199 Watt (economy), 0.5 Watt (standby), On mode power consumption as defined in JBMS-84 197 Watt | | Heat Dissipation | 895 BTU/hour (max) | | Supply Voltage | AC 100 V - 240 V, 50 Hz - 60 Hz | | Product dimensions | 356 x 395 x 133 mm (Width x Depth x Height) | | Product weight | 5.9 kg | | Noise Level | Normal: 37 dB (A) - Economy: 27 dB (A) | | Supported Temperature | Storage -10° C - 60° C | | Supported Humidity | Operation 20% - 80%, Storage 10% - 90% | | | If the projector is suspended from a ceiling or wall mount and installed in an environment with heavy oil smoke or places where oils or chemicals are volatilized, places where a lot of smoke or bubbles are used for event staging, or where aroma oils are frequently burned, it can make certain parts of our products susceptible to a material degradation which over time could break and cause the projector to drop from the ceiling. | | | If you are concerned about the environment in which your projector is installed, or if you have any other questions, please contact our support department and they can provide additional assistance. | | Included Software | Epson Creative Projection, EasyMP Multi PC Projection, Epson Projector Content Manager, Epson Projector Management | | Options | Air filter, Ceiling mount, Connection and control box, External Speaker, Safety wire set, Visualiser camera, WP System - ELPWP10, Wall mount, Wireless LAN unit, Wireless transmitter - ELPWT01 | | Loudspeaker | 16 Watt | | What's in the box | Power cable, Remote control incl. batteries | | Room Type / Application | Boardroom, Home Office, Meeting room / Classroom, Signage / Retail, Visitor Attraction | | Positioning | Ceiling Mounted, Desktop, Table Mounted, Wall Mounted | | Colour | White | |
