| chipset | RTS5411 |
| weight | 42 g |
| gross weight | 0.60 |
| height | 25 mm |
| width | 169.6 mm |
| depth | 46.2 mm |
| data transfer rate | 5000 Mbit/s |
| cable length | 1 m |
| input voltage | 12 V |
| country of origin | CN |
| product colour | Black |
| operating temperature (t-t) | 23 - 133 °F |
| storage temperature (t-t) | -20 - 60 °C |
| operating relative humidity (h-h) | 5 - 95% |
| package width | 205 mm |
| package depth | 132 mm |
| package height | 52 mm |
| package weight | 600 g |
| certification | CE, FCC, RoHS & REACH, CP65 |
| quantity per pack | 1 pc(s) |
| package type | Carton |
| ports quantity | 11 |
| compliance certificates | CE, Federal Communications Commission (FCC), REACH, RoHS |
| manual | Yes |
| housing material | Acrylonitrile butadiene styrene (ABS), Aluminium |
| dc-in jack | Yes |
| input current | 3 A |
| ac adapter included | Yes |
| host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-B |
| hub interfaces | USB 3.2 Gen 1 (3.1 Gen 1) Type-A |
| cables included | USB Type-A to USB Type-B |
| usb power delivery (usb pd) | No |
| included power plug types | AU, EU, UK, US |
| usb 3.2 gen 1 (3.1 gen 1) type-a ports quantity | 10 |
| power supply type | AC |
| net weight | 0.50 |
| packaging height | 5.20 |
| packaging lenght | 20.50 |
| packaging width | 13.20 |
| warranty | 2 |
| tech data sheets | https://files.plytix.com/api/v1.1/file/public_files/pim/assets/30/18/3c/62/623c1830be3c59cb8b1e1693/texts/d1/0d/0e/63/630e0dd1c656d3ffbef05d01/43370_TDS_v1.pdf |
| ce doc | https://files.plytix.com/api/v1.1/file/public_files/pim/assets/30/18/3c/62/623c1830be3c59cb8b1e1693/texts/d9/20/5a/64/645a20d9332284ca4dfdb4f2/CE_43370.pdf |
| ce docs | https://files.plytix.com/api/v1.1/file/public_files/pim/assets/30/18/3c/62/623c1830be3c59cb8b1e1693/texts/d9/20/5a/64/645a20d9332284ca4dfdb4f2/CE_43370.pdf |
| manuals | https://files.plytix.com/api/v1.1/file/public_files/pim/assets/30/18/3c/62/623c1830be3c59cb8b1e1693/texts/35/f5/4f/63/634ff535c83cc392ccfce8a0/Lindy_43370_MAN_1022.pdf,https://files.plytix.com/api/v1.1/file/public_files/pim/assets/30/18/3c/62/623c1830be3c59cb8b1e1693/texts/3e/0e/0e/63/630e0e3ec656d3ffbef05d20/Lindy_43370_MAN_0822.pdf |
| Description |
Specifications - USB Standard: USB 3.2 / 3.1 Gen 1 / 3.0
- Supported Bandwidth: 5 Gbps
- Chipset: RTS5411
- Compatibility: USB Type A equipped computers
- Power Delivery: -
- Special Features: With On/Off Switches, supports Battery Charging 1.2 and Multi TT technology
Connectors - Inputs: 1 x USB Type B (Female)
- Outputs: 10 x USB Type A (Female)
- Power: 5.5/2.1mm DC socket
Physical Properties - Dimensions WxDxH: 169.6 x 46.2 x 25mm (6.68x1.82x0.98in)
- (Fixed) Cable Length: -
- Housing Material: Aluminium Alloy, ABS
- Net Weight: 0.042kg (0.09lb)
- Operating Temperature: -5°C - 56°C (23°F -133°F)
- Storage Temperature: -20°C - 60°C (-4°F -140°F)
- Humidity: 5 - 95% RH (non-condensing)
- Power Requirements: 12V 3A
- Colour: Black
Miscellaneous - Packaging Type: Carton box
- Packaging Dimensions: 205x132x52mm (8.07x5.2x2.05in)
- Gross Weight: 0.6kg (1.3lb)
- Warranty (Years): 2
- Certificated: CE, FCC, RoHS & REACH, CP65
Package Contents - 10 Port USB 3.0 Hub
- 1m USB Type A to B cable
- Multi-Country power supply (EU; UK; US; AUS)
- Lindy Manual
Purchasing Information - No.: 43370
- EAN: 4002888433709
CE Doc: CE_43370.pdf Tech Data Sheets: 43370_TDS_v1.pdf Manuals: Lindy_43370_MAN_0822.pdf
|
|
