    Manufacturer: MSI

    Mainboard|MSI|Intel Z890|LGA1851|ATX|Memory DDR5|Memory slots 4|PROZ890-AWIFI


    €303.14 incl tax

    SKU: ST09311735
    Manufacturer part number: PRO Z890-A WIFI
    Manufacturer Homepage
    Warranty: 36 months
    *
    Stock Delivery Quantity Price
    LT
    LV

    Products specifications
    Form Factor ATX
    Video interface HDMI
    Model

    PRO Z890-A WIFI
    CPU socketLGA1851
    Processor familyIntel Core
    Integrated CPUNo
    Chipset manufacturerIntel
    Chipset type

    INTEL Z890
    Memory type DDR5
    Number of DDR5 slots4
    Memory bus frequency6400 MHz
    Memory bus frequency4800 MHz
    Memory bus frequency7200 MHz
    Memory bus frequency9200 MHz
    Memory bus frequency5600 MHz
    Max memory size 256 (GigaBajt)
    Expansion slots3 x PCIe x 16
    Expansion slots4 x M.2
    Max. number of SATA devices 4
    RAIDNo
    Detailed data on disk/drive interfaces

    Slot

    • 3x PCI-E x16 slot (Qty)
    • PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU)
    • PCI_E2 Gen PCIe 4.0 supports up to x4 (From Chipset)
    • PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset)

    Storage

    • 4x M.2 (Qty)
    • M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices
    • M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260 devices
    • M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices
    • M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices
    • 4x SATA 6G (Qty)

    RAID

    • Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
    • Supports RAID 0, RAID 1, RAID 5 and RAID 10 for M.2 NVMe storage devices
    Graphics
    • 1x HDMI
    • Support HDMI 2.1 with FRL, maximum resolution of 4K 120Hz*
    • 2x Type-C DisplayPort
    • Thunderbolt 4 ports, supporting DisplayPort 2.1 with UHBR20 over USB Type-C, with a maximum resolution of 4K@120Hz / 8K@60Hz
    Sound card
    • Realtek ALC1220P
    • 7.1-Channel High Definition Audio
    • Supports S/PDIF output
    Network interface1 x 10/100/1000/2500/5000 Mbit/s
    Network interfaceWi-Fi 802.11a/b/g/n/ac/ax/be
    Network interfaceBluetooth
    Network interface

    LAN

    • Realtek 8126 5Gbps LAN

    BEZPRZEWODOWA SIEĆ LAN I BLUETOOTH

    • Intel Wi-Fi 7
    • Moduł sieci bezprzewodowej jest fabrycznie zainstalowany w gnieździe M.2 (Key-E).
    • Obsługuje MU-MIMO TX/RX, 2,4 GHz / 5 GHz / 6 GHz* (320 MHz) do 5,8 Gb/s.
    • Obsługuje 802.11 a/ b/ g/ n/ ac/ ax/ be.
    • Obsługuje Bluetooth 5.4**, MLO, 4KQAM.
    USB ports at back panel10
    USB ports on motherboard7
    Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports6
    Number of USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2 ports4
    FireWire (IEEE 1394)No
    COM connector / portNo
    LPT connector / portNo
    External connectors1 x Line Out (front)
    External connectors1 x MIC (front)
    External connectors1 x S/PDIF
    External connectors1 x RJ-45
    External connectors2 x Thunderbolt 4
    External connectors3 x USB 3.2 Gen 2 Type-A
    External connectors1 x HDMI
    External connectors1 x Flash BIOS Button
    External connectors4 x USB 3.2 Gen 1 Type-A
    External connectors1 x USB 3.2 Gen 2 Type-C
    External connectors2 x SMA
    Onboard connectors6 x 4pin wentylator obudowy
    Onboard connectors1 x 8-pin PCIe
    Onboard connectors1 x 2-Digit Debug Code LED
    Onboard connectors1 x Thunderbolt header
    Onboard connectors4 x USB 2.0/1.1
    Onboard connectors1 x RGB LED strip header
    Onboard connectors3 x Addressable LED
    Onboard connectors2 x System panel header
    Onboard connectors2 x USB 3.2 Gen 1 Type-A
    Onboard connectors1 x USB 3.2 Gen 2x2 Type-C
    Onboard connectors4 x EZ Debug LED
    Onboard connectors1 x 4pin CPU/Water Pump Fan Connector
    Onboard connectors1 x TPM header
    Onboard connectors1 x 4pin CPU fan
    Onboard connectors1 x Chassis intrusion header
    Onboard connectors1 x 24pin ATX zasilanie
    Onboard connectors1 x Front panel audio header
    Form factorATX
    Dimensions

    243.84 mm x 304.8 mm
    Supported operating systemsWindows 11
    DesignationCE+WEEE
    Width340
    Height270
    Depth75
    Weight2000
    Description

    PRO Z890-A WIFI

    • Obsługa procesorów Intel Core Ultra (Seria 2) zgodnych z podstawką LGA 1851
    • Dwukanałowa obsługa pamięci DDR5 9200+ MT/s (overclocking)
    • Wyjątkowa wydajność: 16+1+1+1-fazowa, 90-amperowa konstrukcja zasilania zgodna z układem Duet Rail Power System i systemem inteligentnych stopni zasilania SPS, dwa 8-pinowe złącza zasilania procesora, technologie Core Boost i Memory Boost, 6-warstwowa płytka drukowana z dwoma uncjami rozmieszczonej warstwowo miedzi wykonana z materiałów klasy serwerowej
    • System ochrony Frozr Guard: Ulepszona, wydłużona konstrukcja radiatora Extended Heatsink, podkładki termiczne 7W/mK na tranzystorach mocy MOSFET, dodatkowe podkładki termiczne na dławikach oraz złącze z systemem radiatora EZ M.2 Shield Frozr II pozwalają na lepsze odprowadzanie i rozpraszanie ciepła oraz wielogodzinną, nieprzerwaną pracę
    • System EZ DIY: EZ M.2 Shield Frozr II, EZ M.2 Clip II, EZ PCIe Clip II oraz EZ Antenna
    • Wyjątkowa szybkość: złącza PCIe 5.0 i Lightning Gen 5 x4 M.2
    • Ultra Connect: dual Thunderbolt 4 ports, 5G LAN with Intel Wi-Fi 7 Solution - the latest solution for professional and multimedia use, delivering secure, stable, and high-speed networking and data transmission
    • Audio Boost 4: Generowanie dźwięku o jakości studyjnej pozwalającej uzyskać efekt wyjątkowego zanurzenia w grze
    Description
    Intel Z890 | ATX | Audio 7.1 channels | CPU Intel | Socket LGA 1851 (Socket V1) | Series Intel Core Ultra (Series 2) | Supported memory types DDR5-SDRAM | 4xNumber of memory slots | Memory slots type DIMM | Supported storage drive interfaces M.2,SATA III | 4xUSB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3xUSB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1xUSB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1xEthernet LAN (RJ-45) ports | 1xHDMI ports quantity | 1xThunderbolt ports quantity | Wi-Fi Yes | Bluetooth Yes
    DescriptionMSI PRO Z890-A WIFI
    VatTypeVAT
    Weight2.020000000
    Height70.000000000
    Width270.000000000
    Length340.000000000
    Description
    MSI PRO Z890-A WIFI
    Gross depth (mm)150.00
    Gross depth (mm)150.00
    Gross height (mm)40.00
    Gross height (mm)40.00
    Gross weight2.00
    Gross width (mm)120.00
    Gross width (mm)120.00
    Net weight1.10
    Tare weight (kg)0.90
    Tare weight (kg)0.90
    TI weight (kg)0.10
    TI weight (kg)0.10
    Volume (m3)0.00
    Volume (m3)0.00
