Manufacturer: ZYXEL

Zyxel GS1900-8HP v3 PoE Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

€126.19 incl tax

SKU: ST05607889

Manufacturer part number: GS1900-8HP-EU0103F

Manufacturer Homepage

Warranty: 12 months

Stock *

Stock	Delivery	Quantity	Price
PL	9 - 12 days	2	€126.19 incl tax
PL	8 - 15 days	1	€136.60 incl tax
LV	7 - 12 days	39	€150.84 incl tax

Qty:

Specifications

Products specifications

1
Details 2
Details 3
Details 4

RJ-45 port	8
Properties	RJ-45
WRL stadarti	802.11b

Switch class	SMART
Application	Home and small office
Switch layer	L2
Network architecture	GigabitEthernet
Number of 10/100 Mbps ports	None
Number of 10/100/1000 Mbps ports	8
10/100/1000/2500 Mbps ports	None
Number of 10Gb ports	None
Number of PoE ports (PoE & PoE+)	8
Number of PoE+ ports	None
Number of COMBO ports	None
Number of SFP ports	None
Number of SFP+ ports	None
Number of QSFP+ ports	None
Console port	No
Throughput	16 (Gigabity na sek.)
Forwarding rate	11.9 (Mpps)
Packet buffer	525 (Kilobajt)
MAC address table size	8000
Support for Jumbo frames	Yes
Jumbo frame size	9 (Kilobajt)
Stackability	No
VLAN	IEEE 802.1Q VLAN tagging IEEE 802.3ad LACP Guest VLAN Voice VLAN Storm control IEEE 802.1p priority queues per port IEEE 802.1p Queuing method(SPQ/WRR) Input priority mapping Rate limiting per port(ingress/egress) IEEE 802.3x flow control
Supported protocols and standards	IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Ethernet IEEE 802.3ab (1000BASE-T) Ethernet IEEE 802.3x flow control IEEE 802.3az EEE support IEEE 802.1p CoS support IEEE 802.3af PoE (GS1900-8HP/10HP/24HP/48HP) IEEE 802.3at PoE plus (GS1900-8HP/10HP/24HP/48HP) IEEE 802.1D Spanning Tree Protocol (STP) IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) Full-duplex and half duplex operation with IEEE 802.3x flow control and backpressure Store and forward Auto MDI/MID-X
QoS	IEEE 802.1p class of service(SPQ, WRR) Port-based CoS IP TOS precedence
Security	IEEE 802.1x Port security Layer 2 MAC filtering Static MAC forwarding RADIUS TACACS+ SSL Management VLAN CPU defense engine DoS prevention
Management, monitoring, configuration	IPv6 Management: IPv6 over Ethernet (RFC 2464) Dual-stack (RFC 4213) ICMPv6 (RFC 4884) Neighbor discovery (RFC 4861) Auto configuration Static IPv6 address and prefix length Static IPv6 default gateway IPv6 duplicate address detection Manageability: SNMP v1, v2, v3 RMON (1, 2, 3, 9) ICMP echo/echo reply Syslog IEEE 802.1AB LLDP IEEE 802.1AB LLDP-MED LLDP-Power via MDI Device Management: Web interface Remote firmware upgrade by Web Configuration saving and retrieving Firmware upgrade via SNMP DHCP client Daylight saving NTP Port mirroring Scheduled PoE PoE default consumption mode Time range group for scheduled PoE MIB: RFC 1213 MIB II RFC 2819 RMON (group 1, 2, 3, 9) RFC 1215 generic traps RFC 1493 bridge Zyxel private common MIB ZON Utility: Discovery of Zyxel switches, APs and gateways IP configuration IP renew Device factory reset Device reboot Device locating Web GUI access Password configuration One-click quick association with Zyxel AP Configurator (ZAC) Automatic detection of the latest firmware Displays device serial number and hardware version Cloud mode on/off option for Hybrid series devices
L2 features	IGMP snooping (v1, v2, v3)
Chassis type	Desktop
Fan	No
Power supply	External
Power consumption	84.8 (Watt)
Power supply	100 - 240 V AC, 50/60 Hz Maksymalny budżet PoE: 77W
Dimensions	250 x 104 x 27 mm
Weight	0.71 (kilogram)
Certificates	RoHS compliant EMC: CE, FCC, RCM, Class A BSMI CNS 13438 Safety: LVD LVD EN 62368-1 BSMI CNS 14336-1
Designation	CE+WEEE
Width	305
Height	225
Depth	65
Weight	1300

Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Y
Web-based management	Y
Basic switching RJ-45 Ethernet ports quantity	8
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power connector	DC-in jack
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Full duplex	Y
Flow control support	Y
Broadcast storm control	Y
Rate limiting	Y
Auto MDI/MDI-X	Y
VLAN support	Y
MAC address table	8000 entries
Switching capacity	16 Gbit/s
Number of queues	8
Jumbo frames support	Y
Jumbo frames	9216
DHCP features	DHCP client
IGMP snooping	Y
Security algorithms	802.1x RADIUS
MAC address filtering	Y
Multicast support	Y
Product colour	Black
Reset button	Y
Certification	CE, FCC, C-Tick, RoHS
Mean time between failures (MTBF)	533086 h
Power source	AC/DC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	90 W
Power over Ethernet (PoE)	Y
Power over Ethernet (PoE) ports quantity	8
Total Power over Ethernet (PoE) budget	70 W
Operating relative humidity (H-H)	10 - 90%
Width	250 mm
Depth	104 mm
Height	27 mm
Weight	710 g
Harmonized System (HS) code	85176990
Description
Description	Zyxel GS1900-8HP v3 PoE. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. Full duplex. MAC address table: 8000 entries, Switching capacity: 16 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE.... Power connector: DC-in jack. Power over Ethernet (PoE)

auto mdi/mdi-x

Yes

power over ethernet (poe)

Yes

manufacturer

ZYXEL COMMUNICATIONS

product type

Network Switches

weight

710 g

height

27 mm

width

250 mm

depth

104 mm

full duplex

Yes

switch type

Managed

switch layer

quality of service (qos) support

Yes

web-based management

Yes

basic switching rj-45 ethernet ports quantity

basic switching rj-45 ethernet ports type

Gigabit Ethernet (10/100/1000)

power connector

DC-in jack

networking standards

IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x

flow control support

Yes

mac address table

8000 entries

switching capacity

16 Gbit/s

mac address filtering

Yes

multicast support

Yes

product colour

Black

mean time between failures (mtbf)

533086 h

power over ethernet (poe) ports quantity

total power over ethernet (poe) budget

70 W

operating relative humidity (h-h)

10 - 90%

certification

CE, FCC, C-Tick, RoHS

harmonized system (hs) code

85176990

power source

AC/DC

ac input voltage

100 - 240 V

ac input frequency

50 - 60 Hz

jumbo frames support

Yes

power consumption (typical)

90 W

security algorithms

802.1x RADIUS

reset button

Yes

jumbo frames

9216

igmp snooping

Yes

vlan support

Yes

broadcast storm control

Yes

rate limiting

Yes

dhcp features

DHCP client

number of queues

Description

Zyxel GS1900-8HP v3 PoE. Slēdža tips: Vadīts, Slēdža līmenis: L2. Basic switching RJ-45 Ethernet portu veids: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet portu daudzums: 8. Pilns duplekss. Adrešu tabulas izmērs: 8000 ieraksti, Komutācijas ietilpība: 16 Gbit/s. Tīkla standarts: IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE.... Saspraudnis: DC-ligzda. Power over Ethernet (PoE)
