Manufacturer: EATON

Eaton 9SX uninterruptible power supply (UPS) Double-conversion (Online) 1.5 kVA 1350 W 6 AC outlet(s)

€1346.09 incl tax

SKU: ST03305402

Manufacturer part number: 9SX1500I

Manufacturer Homepage

Warranty: 12 months

Stock *

Stock	Delivery	Quantity	Price
DE	5 - 10 days	5	€1346.09 incl tax
PL	8 - 15 days	6	€1441.28 incl tax
LV	7 - 12 days	3	€1612.01 incl tax
PL	9 - 12 days	1	€1644.20 incl tax

Qty:

Specifications

Products specifications

1
Details 2
Details 3
Details 4
Details 5
Details 6
Details 7

UPS voltage regulators	1500
Socket (USB)	yes
Socket (RS232)	yes
Output power	1350
Tips	Online
Tips	Double Conversion Online
Socket (IEC320)	yes

Apparent power	1500 VA
Active power	1350 (Watt)
UPS Architecture	on-line double conversion
Number of phases input	1 (230V)
Voltage	230 (Volt)
Charging time	50 (Minute)
Chassis type	Tower
Filters / protection	Overdischarge
Input power ports	IEC-C14
Output power ports	6 x IEC-C13
I/O connectors	1 x RS-232 (COM)
I/O connectors	1 x USB 2.0
Environment requirements	Temperatura podczas pracy: 0-40 st.C Poziom hałasu: 43 dB
Accessories included	Przewody wyjściowe IEC10A (1,8 m) x 2 Kabel USB (1,8 m) Przewód szeregowy (1,8 m) Krótka instrukcja obsługi Wskazówki dotyczące bezpieczeństwa
Color	Black
Dimensions	252 x 160 x 437 mm
Weight	18.5 (kilogram)
Other features	Blok mini-zacisków do zdalnego wyłączania zasilania (konfigurowalny) Blok mini-zacisków do przekaźnika wyjściowego Gniazdo do opcjonalnego modułu komunikacyjnego
Video
Video
Designation	CE+WEEE
Width	570
Height	370
Depth	290
Weight	21000
Description
Description	Zasilacz UPS z podwójną konwersją online 1500 VA/1350 W, wielojęzyczny wyświetlacz LCD, licznik energii, 6 gniazd IEC 10 A (2 zarządzalne grupy), gniazdo na opcjonalną kartę zarządzania, USB i porty szeregowe, styki bezpotencjałowe, złącze RPO, oprogramowanie do zarządzania zasilaniem kompatybilne z wirtualnym środowiskiem, baterie wymienialne podczas pracy urządzenia, długi czas pracy awaryjnej z czterema opcjonalnymi modułami EBM.

UPS topology	Double-conversion (Online)
Output power capacity	1.5 kVA
Output power	1350 W
Waveform	Pure sine
Input operation voltage (min)	190 V
Input operation voltage (max)	276 V
Input frequency	40/70 Hz
Output operation voltage (min)	200 V
Output operation voltage (max)	240 V
Output frequency	50/60 Hz
Number of input phases	1
Number of output phases	1
Power factor	0.9
ECO mode	No
Noise level	43 dB
AC outlet types	C13 coupler
Power plug	C14 coupler
AC outlets quantity	6 AC outlet(s)
USB port	Yes
USB 2.0 ports quantity	1
Serial interface	Yes
Serial interface type	RS-232
RS-232 ports	1
Battery technology	Sealed Lead Acid (VRLA)
Typical backup time at half load	16 min
Hot-swap battery	Yes
Automatic battery test	Yes
Form factor	Tower
Product colour	Black
Display type	LCD
Safety	IEC/EN 62040-1, UL 1778, CSA 22.2
Certification	IEC/EN 62040-1, UL 1778, CSA 22.2, IEC/EN 62040 -2 , FCC Class B, CISPR22 Class B, CE /CB report (TUV) / cULus / EAC / RCM / BIS / KCC
Operating temperature (T-T)	0 - 40 °C
Width	160 mm
Depth	437 mm
Height	252 mm
Weight	24.5 kg
Management card included	No
Bundled software	Intelligent Power Software suite
Harmonized System (HS) code	85078000
Input connection type	IEC C14
Nominal output voltage	230 V
Nominal input voltage	230 V
Description
Description	Eaton 9SX. UPS topology: Double-conversion (Online), Output power capacity: 1.5 kVA, Output power: 1350 W. AC outlet types: C13 coupler, Power plug: C14 coupler, AC outlets quantity: 6 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Typical backup time at half load: 16 min. Form factor: Tower, Product colour: Black, Display type: LCD. Width: 160 mm, Depth: 437 mm, Height: 252 mm

Description
	1350 Watts \| 1500 VA \| Topology OnLine DoubleConvertion \| Phase 1phase \| Input ports Single, IEC320 C14 (10AMP) \| Output power connector type IEC 320 C13 (10A)

manufacturer

Eaton

product group

USV

product type

UPS Online

colour

black

weight

18.5 kg

height of packaging (single piece)

0 mm

width of packaging (single piece)

0 mm

depth of packaging (single piece)

0 mm

package weight (single piece)

18.5 kg

gross weight

18.5

current catalog edition

24.1

current catalog page

10.11

height

0.380

width

0.300

depth

0.570

operating temperature min.

-20 °C

operating temperature max.

40 °C

dimensions (hxwxd)

252 x 160 x 437 mm

interface

RS232, USB, MS-Slot, EPO

mounting form

Turm

rs-232 interface

usb 2.0 interface

conformity

IEC/EN 62040-1, UL 1778, CSA 22.2; IEC/EN 62040 -2 , FCC ...

acoustic level

<43dB

classification (iec 62040-3)

VFI-SS-111

ups technology

Online

output (va/w)

1500 / 1350

backup time full/half-load

5 / 16 min

voltage (input)

190- 276 V without derating; 120 - 276 V with derating

voltage (output)

200/208/220/230/240V

frequency

40-70Hz, 50/60Hz autoselection, frequency converter mode

connector type (input)

C14

connector type (output)

(6) C13

phase in/output

230V/230V / 50Hz

over current protection

EMI,- RFI-Filter

slot for adapter card

MS-Slot

additional over current protector

nein

activity display

multilinugual

incl.management software

für die gängigen OS

internal cooling

Aktiv, Lüfter

ambient temperature

Elektronik -20°C bis +40°C; Batterien 20°C bis 25°C nach ...

output voltage regulation

+/-??????????????%

hot swap batteries

Ja, Frontseite

bypass

automatisch + manuell

activity led

efficiency

????????????????????????????? %

delay expansion unit

backup time

5 min

max. quantity of delay expansion units

Description

Description	EATON 9SX 1500i
VatType	VAT
Weight	20.920000000
Height	300.000000000
Width	380.000000000
Length	575.000000000
Description
Description	EATON 9SX 1500i

Description	EATON 9SX 1500i
VatType	VAT
Weight	20.920000000
Height	300.000000000
Width	380.000000000
Length	575.000000000
Description
Description	EATON 9SX 1500i
