| manufacturer | ATEN |
| product group | KVM switches / PC shares |
| product type | KVM-Switch, DVI |
| colour | grey |
| weight | 0.56 kg |
| height of packaging (single piece) | 220 mm |
| width of packaging (single piece) | 330 mm |
| depth of packaging (single piece) | 100 mm |
| package weight (single piece) | 1.98 kg |
| gross weight | 1.98 |
| current catalog edition | 24.1 |
| current catalog page | 3.11 |
| technical particularity | LEDs for easy status monitoring |
| scope of delivery | 1 x CS1641A USB-KVMP™-Switch mit 2 Ports für DVI-Monitore... |
| height | 45 mm |
| width | 76 mm |
| depth | 262 mm |
| dimensions (hxwxd) | 45 x 76 x 262 mm |
| material (casing) | metal |
| quantity of pcs | 2 |
| supported pc-systems | USB |
| pc: monitor connection | 2x 2x DVI M |
| pc: mouse/keyboard connection | 2x USB Type B F |
| quantity of digital consoles | 2 |
| print button on device | no |
| switching over hot keys | Keyboard |
| 19" compatible | no |
| cascadable | no |
| hot plug compatible | no |
| max. resolution (nominal) | 2560 x 1600 |
| power supply unit required | yes |
| power supply output | 5,3V 2A DC |
| pc: connection on moulded cables | no |
| switching over scan run | yes |
| switching over osd | no |
| audio switching separately | yes |
| keyboard/mouse emulation | yes |
| mains connection | Appliance Europlug, Type-C |
