| manufacturer | Eaton |
| product group | USV |
| product type | UPS Offline |
| colour | black |
| weight | 4.1 kg |
| height of packaging (single piece) | 160 mm |
| width of packaging (single piece) | 290 mm |
| depth of packaging (single piece) | 330 mm |
| package weight (single piece) | 4.712 kg |
| gross weight | 4.712 |
| current catalog edition | 24.1 |
| scope of delivery | USV, Software, Kabelsatz |
| height | 0.280 |
| width | 0.140 |
| depth | 0.340 |
| operating temperature min. | 0 °C |
| operating temperature max. | 40 °C |
| dimensions (hxwxd) | 263x81x235 mm |
| interface | USB |
| mounting form | Tower |
| usb 2.0 interface | ja |
| classification (iec 62040-3) | VFI-SS-111 |
| ups technology | Offline |
| output (va/w) | 800 / 500 |
| backup time full/half-load | 2 / 11 min |
| voltage (input) | 184-264 V |
| voltage (output) | 230V |
| frequency | 50 Hz |
| connector type (input) | IEC320 C 14 |
| connector type (output) | 4 x C13 |
| phase in/output | 230V/230V / 50Hz |
| over current protection | EMI,- RFI-Filter |
| slot for adapter card | nein |
| additional over current protector | Telefon/Fax/DSL |
| activity display | nein |
| incl.management software | Windows |
| internal cooling | passiv |
| ambient temperature | 0°C bis +40°C; Batterien 20 - 25°C nach EUROBAT |
| hot swap batteries | nein |
| bypass | nein |
| activity led | eine LED |
| delay expansion unit | nein |
