Ražotājs: LEVELONE

Level One LevelOne XEL-0891 Vadīts L3 10G Ethernet (100/1000/10000) Desktops Pelēks

€499,03 ar pvn

Artikuls: ST10000346

Preces kods: XEL-0891

Ražotāja mājaslapa

Garantija: 12 mēneši

Pieejamība *

	Noliktava	Piegāde	Daudzums	Cena
	LV	7 - 12 dienās	50	€499,03 ar pvn

Daudzums:

Specifikācijas

Specifikācija

power over ethernet (poe)

weight

1.1 kg

height

37.8 mm

width

220 mm

depth

130 mm

full duplex

Yes

switch type

Managed

country of origin

China

switch layer

quality of service (qos) support

Yes

web-based management

Yes

basic switching rj-45 ethernet ports quantity

basic switching rj-45 ethernet ports type

10G Ethernet (100/1000/10000)

power connector

DC-in jack

networking standards

IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az, IEEE 802.3ae, IEEE 802.1Q, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ab, IEEE 802.3ad, IEEE 802.3bz, IEEE 802.3z

10g support

Yes

flow control support

Yes

link aggregation

Yes

mac address table

16000 entries

switching capacity

160 Gbit/s

forwarding rate

119.04 Mpps

packet buffer memory

12 MB

multicast support

Yes

form factor

Desktop

product colour

Grey

led indicators

Yes

mean time between failures (mtbf)

50000 h

power consumption (max)

29.6 W

operating temperature (t-t)

0 - 40 °C

storage temperature (t-t)

-40 - 70 °C

operating relative humidity (h-h)

10 - 90%

storage relative humidity (h-h)

5 - 90%

package width

310 mm

package depth

200 mm

package height

80 mm

package weight

1.5 kg

harmonized system (hs) code

8517620000

package type

Box

power source

input current

3 A

cables included

LAN (RJ-45) to DB9

jumbo frames support

Yes

shipping (inner) case height

21.8 cm

shipping (inner) case width

42.3 cm

shipping (inner) case length

32.3 cm

products per shipping (inner) case

5 pc(s)

shipping (inner) case gross weight

8.5 kg

quick start guide

Yes

jumbo frames

12000

igmp snooping

Yes

power supply included

Yes

spanning tree protocol

Yes

dc input voltage

12 V

static route

Yes

vlan support

Yes

system event log

Yes

sfp+ module slots quantity

broadcast storm control

Yes

rate limiting

Yes

dhcp features

DHCP relay, DHCP snooping, DHCP Option 82, DHCP Option 43, DHCP Option 60, DHCP Option 61, DHCP Option 67, DHCP client

console port

RJ-45

multicast listener discovery (mld) snooping

igmp proxy

Yes

Description

LevelOne XEL-0891. Slēdža tips: Vadīts, Slēdža līmenis: L3. Basic switching RJ-45 Ethernet portu veids: 10G Ethernet (100/1000/10000), Basic switching RJ-45 Ethernet portu daudzums: 4, Konsoles pieslēgvieta: RJ-45. Pilns duplekss. Adrešu tabulas izmērs: 16000 ieraksti, Komutācijas ietilpība: 160 Gbit/s. Tīkla standarts: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az, IEEE 802.3ae, IEEE 802.1Q, IEEE.... DC ievades spriegums: 12 V. Saspraudnis: DC-ligzda. Formas faktors: Desktops
