| Description | DELL R450 4309Y 8C/16GB/480GB/H355/1X1100W/4X3.5"/3BW |
| CountryofOrigin | POLAND |
| PictureLocation | https://www2.f9baltic.com/productimages/big/R450-front.png |
| ThumbnailPictureLocation | //www2.f9baltic.com/productimages/thumb/R450-front.png |
| AdditionalPictures |
|
| Weight | 16.364954 |
| Height | 0.000000 |
| Length | 0.000000 |
| Width | 0.000000 |
| BoxSize | 0 |
| PalletSize | 0 |
| Chase type | Rack (1U) |
| Maximum internal memory, GB | 1 TB |
| Number of processors supported | 2 |
| Hard disk size, " | 3.5 |
| Ethernet LAN (RJ-45) ports quantity | 2 |
| Number of processors installed | 1 |
| Number of power supplies max. | 2 |
| Number of hard drives supported | 4 |
| Internal memory | 16 GB |
| Processor model | Intel Xeon Silver 4309Y (Max. 3.60 GHz, 12M, 8C) |
| Processor number of cores | 8 |
| Processor clock speed, GHz | 2.80 |
| Hot-swap (HS) hard disk (-s) | Yes |
| Total storage capacity | 480 GB |
| Memory slots | 16 |
| Internal memory type | DDR4 RDIMM |
| Power supply, W | 1100 |
| Processor manufacturer | Intel |
| Memory clock speed, MHz | 3200 |
| Dimensions W x D x H, mm | 482 x 713 x 42.8 |
| Memory slots (available) | 15 |
| RAID levels | 0,1,10 |
| Number of power supplies | 1 |
| Hard disk controller | DELL PERC H355 |
| Number of hard drives installed | 1 |
| Redundant power supply (RPS) support | Yes |
| Remote administration | Dell iDRAC9 Enterprise 15G |
| Description |
Density-optimized general-purpose server
The Dell PowerEdge R450 is a two-socket entry-level 1U server offering updated technologies and added value with faster processing speeds and flexible storage options.
Supports up to 24 cores per CPU, and up to 16x DDR4 RDIMMs at up to 3200 MT/s
Built with a minimum footprint and enterprise compute to fit into a variety of environments
Manage with iDRAC9 Enterprise, OpenManage Enterprise and Plugins, iDRAC Direct, and Quick Sync 2.0
Full-stack management integration with Microsoft, VMware, ServiceNow, Ansible and many other tools for on-premises, edge and cloud environments
Model specific features
- Processor: Xeon Silver 4309Y 8C/16T, 2.8GHz (3.6GHz Max), can be duplicated*
- Memory: 16Gb (1x16Gb RDIMM 3200Mhz Dual Rank), 16 memory slots*
- Disk drive: 480Gb RI SATA SSD 2.5" in 3.5" hot-plug, 4 disk slots 3.5"
- Raid-controller: DELL PERC H355, Front load (RAID 0/1/10)
- Network interfaces: 2x 1GbE (Broadcom LOM)
- Available PCIe slots: 1x OCP3.0, 1x Low Profile (Riser config 0)
- Remote management: iDRAC9 Enterprise 15G
- Sliding ReadyRails
- Power supply: 1x 1100W Titanium hot-plug, redundant option available
- Support: 3 year Basic parts warranty
* 8 memory slots per CPU * for adding second cpu, two additional fans needed (SKU 384-BCZS) |
