PrevArctic Freezer P12 Pro Reve...

NextArctic Freezer P12 Pro Reve...

Производитель: ARCTIC

Arctic Freezer P12 Pro Reverse A-RGB (White) Datora korpusam Ventilators 12 cm Balts 1 pcs

€16,95 с налогом

Артикул: ST09970232

Код производителя: ACFAN00325A

Сайт производителя

гарантия: 24 месяцы

Stock *

Склад	Доставка	Наличие	Цена
LT	2 - 4 дня	10	€16,95 с налогом
PL	8 - 15 дня	10	€29,86 с налогом

Количество:

Specifications

Характеристики

1
Details 2
Details 3

Применение	для корпуса 120 mm.
Применение	для корпуса 80 mm.

cable length

0.48 m

type

Fan

product colour

White

operating temperature (t-t)

0 - 40 °C

package width

125 mm

package depth

127 mm

package height

32 mm

package weight

210 g

quantity per pack

1 pc(s)

package type

Box

number of fans

1 fan(s)

fan diameter

12 cm

screws included

Yes

number of screws

4

warranty period

6 year(s)

illumination colour

Multi

airflow

124 m³/h

suitable location

Computer case

maximum airflow

73 cfm

pulse-width modulation (pwm) support

Yes

bearing type

Fluid Dynamic Bearing (FDB)

number of fan blades

5

fan connector

4-pin

fan dimensions (w x d x h)

120 x 120 x 27 mm

starting voltage

3.5 V

fan speed (max)

3000 RPM

illumination led

Yes

fan voltage

12 V

fan current

0.4 A

fan weight

172 g

led connector type

3-pin + 3-pin

fan speed (min)

500 RPM

fan static pressure

4.5 mmH2O

led voltage

5 V

Description

ARCTIC Freezer P12 Pro Reverse A-RGB (White). Tips: Ventilators, Ventilatora diametrs: 12 cm, Gaisa plūsma: 124 m³/h, Gultņa veids: Hidrodinamiskais gultnis (FDB). Produkta krāsa: Balts

Description

PWM Fan P12 Pro Reverse A-RGB, -pin, 120mm, white with A-RGB.rFeatures:uReversed Airflowu. The P12 Pro Reverse is specifically designed for air intake from the ack side. It's particularly suitale when conventional fans would compromise the aesthetics.uEfficient Performance at High Air Resistanceu. Thanks to high static pressure, the Pro fans move air effectively through tight spaces. This makes them ideal for radiators, perforated panels, and mesh filters.uPST – PWM-Based Synchronized Fan Controlu. An additional PWM connector allows multiple fans to e synchronized in series using a single header.uOptimized Bearing-Shaft Design (FDB)u. A hydrodynamic earing comined with an etended shaft ensures quieter operation y improving pressure distriution and minimizing virations.uSOTA Microcontrolleru. Reduces motor noise, compensates for load fluctuations, and protects against inrush currents and reverse polarity.uMore Power – Less Noiseu. An automated measuring and alancing process ensures smooth performance y applying the alancing compound with pinpoint accuracy.uOptimized Airflow Designu. The trumpet-shaped intake and teardrop-shaped spokes direct the airflow with reduced flow losses. This reduces air resistance, minimising turulence and aerodynamic noise.uMinimum Gap Dimensions for Maimum Efficiencyu. Enales higher static pressure and maimum airflow efficiency.rSpecifications:Fan speed: 500-3000 RPM PWM controlled, 0 rpm elow 5 % PWM.Air flow: 73 CFM 12 m³h.Static pressure: .5 (mm H2O).Fan earing: Fluid Dynamic Bearing.Current voltage: 0.A 12V DC.Connection: -Pin Fan Plug + -Pin Socket.Cale length: 00 mm + 80 mm Daisy-Chain Cale.LED: 12 A-RGB Gen2.RGB voltage current: 5V DC 0.0A.LED connector: 3-Pin A-RGB Plug + 3-Pin Socket.Size: 12012025 mm.Weight: 172 g.Color: white ody, optional lighting.rWarranty: 6 years.
