| operating voltage | 5 V |
| weight | 64 g |
| maximum data transfer rate | 5 Gbit/s |
| height | 16.4 mm |
| width | 100 mm |
| depth | 50 mm |
| country of origin | CN |
| power connector | USB Type-C |
| product colour | Black |
| operating temperature (t-t) | 0 - 45 °C |
| storage temperature (t-t) | -20 - 60 °C |
| operating relative humidity (h-h) | 20 - 60% |
| package width | 112 mm |
| package depth | 154 mm |
| package height | 40 mm |
| package weight | 160 g |
| compliance certificates | CE, Federal Communications Commission (FCC), REACH, RoHS |
| housing material | Acrylonitrile butadiene styrene (ABS), Aluminium |
| cables included | USB |
| sustainability compliance | Yes |
| usb 3.2 gen 1 (3.1 gen 1) type-a ports quantity | 6 |
| packaging height | 4.0 |
| packaging lenght | 15.4 |
| packaging width | 11.2 |
| warranty | 2.0 |
| ce doc | https://files.plytix.com/api/v1.1/file/public_files/pim/assets/30/18/3c/62/623c1830be3c59cb8b1e1693/texts/9c/8e/9e/65/659e8e9c8452f9b72f1e71e5/CE_43387.pdf |
| Description |
Specifications - USB Standard: USB 3.2 / 3.1 Gen 1 / USB 3.0
- Supported Bandwidth: 5 Gbps
- Chipset: RTS5411, GPD8104B, AWS3410
- Compatibility: USB Type A equipped computers
- Power Delivery: -
- Special Features: Switching by button; backwards compatible with USB 2.0 / 1.1
Connectors - Inputs: 2 x USB Type A (Female)
- Outputs: 4 x USB Type A (Female), 3.5mm Audio (out)
- Power: USB Type C socket
Physical Properties - Dimensions WxDxH: 100x50x16.4mm (3.94x1.97x0.65in)
- (Fixed) Cable Length: -
- Housing Material: ABS, Aluminium Alloy
- Net Weight: 0.064kg (0.14lb)
- Operating Temperature: 0°C - 45°C (32°F - 113°F)
- Storage Temperature: -20°C - 60°C (-4°F - 140°F)
- Humidity: 20 - 60% RH ( non-condensing)
- Power Requirements: 5V, 1A - 5A
- Colour: Black
Miscellaneous - Packaging Type: Carton box
- Packaging Dimensions: 154x112x40mm (6.06x4.41x1.57in)
- Gross Weight: 0.22kg (0.49lb)
- Warranty (Years): 2
- Product Compliance: CE, FCC, RoHS & REACH, California Proposition 65
Package Contents - USB 3.0 Sharing Switch 4:2
- 2x 1.2m USB 5Gbps Type A cable (Male/Male)
- Lindy Manual
Purchasing Information - No.: 43387
- EAN: 4002888433877
|
|
