Total power | 550 W |
AC input voltage | 200 - 240 V |
AC input frequency | 50/60 Hz |
Input current | 5 A |
Power Factor Correction (PFC) type | Active |
Combined power (+3.3V) | 110 W |
Combined power (+12V) | 540 W |
Combined power (+5V) | 110 W |
Combined power (-12V) | 3.6 W |
Combined power (+5Vsb) | 15 W |
Max output current (+3.3V) | 17 A |
Max output current (+12V) | 45 A |
Max output current (-12V) | 0.3 A |
Max output current (+5Vsb) | 3 A |
Hold time | 14 ms |
Efficiency | 88% |
Power Good signal delay range | 100 - 500 ms |
Power protection features | Over power, Over voltage, Short circuit, Under voltage |
Motherboard power connector | 24-pin ATX |
Peripheral (Molex) power connectors (4-pin) | 3 |
Number of SATA power connectors | 6 |
EPS power connector (4+4 pin) | Y |
PCI Express power connectors (6+2 pin) | 2 |
ATX Power connector (24-pin) | Y |
Cabling type | Non-Modular |
Purpose | PC |
Power supply unit (PSU) form factor | ATX |
80 PLUS certification | 80 PLUS Silver |
ATX version | 2.52 |
Bearing technology | HDB |
Mean time between failures (MTBF) | 100000 h |
Certification | CCC, CE, TUV-RH, RCM, EAC, cTUVus, FCC, BSMI, KC, CB |
Product colour | Black |
Cooling type | Active |
Fan diameter | 12 cm |
Number of fans | 1 fan(s) |
On/off switch | Y |
Width | 150 mm |
Depth | 140 mm |
Height | 86 mm |
Weight | 1.27 kg |
Package width | 190 mm |
Package depth | 245 mm |
Package height | 110 mm |
Package weight | 1.67 kg |
Noise level (quiet mode, 50%) | 18.4 dB |
Noise level (full-load mode, 100%) | 31.2 dB |
Description |
Cooler Master MWE 550 Bronze 230V V2. Total power: 550 W, AC input voltage: 200 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 24-pin ATX, Cabling type: Non-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Silver. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Width: 150 mm, Depth: 140 mm, Height: 86 mm |
